To update your maps, install the Aliance CONNECT toolbox application onto your computer. Please note, you may need to disable anti-virus and security software to allow the Alliance CONNECT toolbox application to run.

You will also need a good quality USB (8GB-32GB, no larger). Ensure the USB is formatted correctly to FAT32.

STEP 1 - Retrieving your vehicle information

• Get into your vehicle with a USB key (8GB-32GB), start the engine and turn on the EASY LINK screen
• Plug the USB key into your vehicle's USB port (make sure that no other USB key is connected) and wait 10 seconds.
• Even if your screen is blank, your USB key is working to retrieve your system's configuration data. You can remove the USB key after 10 seconds.Note, to confirm which version of the map your vehicle already has in the Easy Link multimedia system, go to the vehicle's main menu → Car info → System → Map Update → Australia

STEP 2 - Synchronising the Toolbox

• On your computer, launch the Toolbox and connect the same USB key used in the above steps. The toolbox will detect your vehicles information automatically and recommend updates available for your system.
• If several updates are available (your system software and maps), we recommend completing them all.

STEP 3 - Downloading updates to your USB key

• Download the updates to your USB key using your computer. Note: Download time may vary depending on the speed of your internet connection and the size of the map file.
• Do not interrupt the process before the download is complete.
• Once the download is complete, disconnect your USB key from your computer properly.

STEP 4 - Updating maps on board the vehicle

• Return to your vehicle with the USB key, start the engine and turn on the EASY LINK screen.
• Plug the USB key containing the updates into your vehicle's USB port. The update will be displayed on the screen. Tap OK to launch the process. Depending on the size of the map, this may take several minutes.
• Do not turn off the engine during the operation. Do not remove the USB key, and do not use your EASY LINK system. However, you can begin driving. Navigation will become available as soon as the update is complete.
• A message will appear on the screen to confirm that the installation is complete. Wait until this message is displayed. You can now use the new maps.

STEP 1

Insert a USB key to your navigation device and save its navigation data.

STEP 2

Download the Toolbox to your computer and insert the USB drive

STEP 3

Follow the instructions on the screen to update your map

STEP 4

Re-insert the USB key into your navigation device and upload the data

For detailed information, see the guide menu.
